6. TREND

In order to examine the logged data and events, the program offers a basic trend display.

The program offers the following possibilities:

• Date and time filter

• Log event filter

• Device error event filter

• Selectable value on the right axis

• Printing

The primary value is displayed on the left side of the axis (PV according to P01, see manual). If the operation mode of the primary value changes

during logging the user should pay attention to it (E.g.: by filtering to the appropriate time interval).

figure 7
